Product Overview

Excellence in Design and Function

The Stahlock Lever Set series delivers the perfect balance of aesthetics, functionality, and durability. Each model features tubular or cylindrical construction with options ranging from traditional brass to contemporary stainless steel. Our leversets accommodate various door preparations while providing ADA-compliant operation and master key capabilities.

Brass Lever Series - 800 Collection

Model 809 SBET - Premium Brass Entry Lever

Elegant Wave Design for Distinguished Entries

Specifications:

• Style: Elegant wave profile lever

• Finish: Satin brass (SB) with protective coating

• Function: Entry with keyed cylinder

• Backset: Adjustable 2-3/8" or 2-3/4"

• Rose: 2-3/4" diameter decorative

• Door Thickness: 1-3/8" to 1-3/4" standard

Features:

• Solid brass construction

• 5-pin cylinder with brass keys

• Reversible for all door handings

• Lifetime mechanical warranty

• Smooth spring-loaded return

Security:

• Pick-resistant cylinder

• Hardened steel latch

• Reinforced roses

• Master key compatible

Model 803 SBET - Classic Brass Entry Lever

Traditional Design with Modern Performance

Specifications:

• Profile: Classic curved lever

• Material: Solid brass construction

• Finish: Satin brass electroplated

• Cylinder: 5-pin tumbler standard

• Installation: Standard tubular prep

• Weight: 3.2 lbs per set

Design Elements:

• Timeless aesthetic appeal

• Ergonomic lever design

• Concealed screws

• Adjustable latch

• Coordinated escutcheons

Model 805PBET - Polished Brass Entry

Mirror Finish Luxury

Specifications:

• Finish: High-polish brass with lacquer

• Design: Traditional curved lever

• Function: Keyed entry

• Interior: Thumb turn option

• Testing: 300,000 cycles

• Compliance: ANSI Grade 2

Model 809 PBET - Wave Profile Entry

Architectural Statement Design

Specifications:

• Style: Distinctive wave curve

• Finish: Polished brass

• Material: Investment cast brass

• Security: 6-pin option available

• Rose Style: Decorative round

• Application: Premium residential

Stainless Steel Series - 6491 & LH800 Collections

Model 6491 SSET - Commercial Stainless Entry

Heavy-Duty Stainless Steel Construction

Specifications:

• Material: Grade 304 stainless steel

• Finish: Satin brushed

• Function: Entry/office

• Testing: 500,000+ cycles

• Load: 90kg lever force

• Fire Rating: FD30/60 compatible

Commercial Features:

• Hospital-grade construction

• Anti-bacterial properties

• Vandal-resistant design

• Maintenance-free bearings

• Weather-resistant

Model LH851 - Architectural Stainless Lever

Contemporary Commercial Design

Specifications:

• Profile: Straight architectural

• Material: Solid stainless steel

• Rose: Square 52mm profile

• Spindle: 8mm heavy-duty

• Bearing: Dual ball bearing

• Warranty: 10-year mechanical

Model LH855 - Curved Stainless Lever

Ergonomic Professional Grade

Specifications:

• Design: Ergonomic curve profile

• Material: SS304 standard

• Finish: Brushed satin

• Testing: EN 1906 Class 4

• Operation: ADA compliant

• Application: High-traffic areas

Model LH853 SNET - Satin Nickel Entry

Premium Nickel-Plated Design

Specifications:

• Finish: Satin nickel over brass

• Style: Contemporary straight

• Function: Entry with deadlocking

• Cylinder: 6-pin security option

• Rose: Concealed fix design

• Durability: Salt spray tested

Model LH854 - Standard Stainless Lever

Versatile Commercial Solution

Specifications:

• Material: Stainless steel 304

• Profile: Classic curve

• Testing: 400,000 cycles

• Functions: All available

• Installation: Universal handing

• Price Point: Competitive

Model LH853 BNBK - Black Nickel Lever

Modern Matte Black Design

Specifications:

• Finish: Black nickel (BN/BK)

• Style: Contemporary aesthetic

• Material: Brass with black plating

• Durability: Scratch-resistant

• Trend: Architectural black

• Application: Modern interiors

Model LH852SSET - Square Rose Stainless

Minimalist Square Design

Specifications:

• Rose: Square profile design

• Material: SS304 solid

• Lever: Straight or curved

• Mounting: Concealed screws

• Testing: 500,000 cycles

• Style: Architectural minimal

Premium Series - LH852 Collection

Model LH852 ABBK - Antique Brass/Black

Two-Tone Designer Finish

Specifications:

• Finish: Antique brass with black accents

• Design: Premium architectural

• Material: Solid brass construction

• Rose: Decorative square

• Features: Living finish

• Application: Luxury projects

Designer Elements:

• Unique two-tone aesthetic

• Hand-finished details

• Coordinated hardware suite

• Premium packaging

• Limited availability

Model LH852 SSET - Premium Stainless Entry

Executive Grade Lever Set

Specifications:

• Grade: Commercial Grade 1

• Material: Premium SS316 option

• Testing: 1,000,000 cycles

• Security: High-security cylinder

• Installation: Professional grade

• Warranty: Lifetime mechanical

Model LH852 BNPS - Black Nickel Privacy

Contemporary Privacy Solution

Specifications:

• Function: Privacy/bathroom

• Finish: Black nickel plated

• Inside: Push button lock

• Outside: Emergency release

• Indicator: Optional occupied

• Style: Modern minimal

Technical Lever Series

Model 808 SNET - Satin Nickel Entry

Technical Specifications Detailed

Complete Specifications:

• Material: Zinc alloy with steel chassis

• Finish: Satin nickel electroplated

• Backset: 60mm or 70mm adjustable

• Door Range: 35-45mm standard

• Extended: Up to 60mm available

• Life Cycle: 200,000+ guaranteed

Installation Features:

• Tubular design for easy installation

• Can be keyed alike with deadbolts

• Master key capability

• Solid steel chassis and latch case

• Exposed trim options available

Model 8803SSET - Stainless Entry Lever

Enhanced Stainless Construction

Specifications:

• Material: Grade 304 stainless

• Rose: 57mm diameter

• Backset: 60/70mm adjustable

• Latch: 12mm throw

• Strike: 70mm available

• Functions: Entry, privacy, passage

Model 8826SNET - Contemporary Entry

Modern Curved Design

Specifications:

• Profile: Contemporary curve

• Material: Zinc with steel core

• Rose: 2-3/4" decorative

• Door Thickness: 35-45mm

• Extended Options: 50-70mm

• Installation: Field reversible

Model 3431SNET - Architectural Lever

Sleek Professional Design

Specifications:

• Style: Architectural straight

• Material: Solid construction

• Length: 127mm lever

• Rose: Contemporary style

• Testing: Commercial grade

• Application: Office buildings

Dimensional Specifications Table

Standard Lever Dimensions

Legend:

• A: Rose diameter

• B: Overall lever length

• C: Door thickness range

• D: Backset dimension (adjustable)

Core Features & Benefits

Construction Excellence

• Chassis: Solid steel with zinc plating

• Latch Case: Die-cast zinc alloy

• Springs: Heavy-duty steel

• Bearings: Maintenance-free

• Mounting: Through-bolt security

Security Features

• Deadlocking: Automatic engagement

• Cylinder Options: 5 or 6-pin

• Anti-Drill: Hardened inserts

• Master Key: Full capability

• Keyed Alike: Coordinate with deadbolts

Design & Comfort

• Ergonomics: ADA compliant force

• Return Spring: Consistent action

• Reversible: Field adjustable

• Styles: Contemporary to traditional

• Finishes: Multiple options

Functions Available

Entry Function

• Outside: Locked/unlocked by key

• Inside: Lever always free

• Deadlocking latch standard

• Master key compatible

• Emergency egress assured

Privacy Function

• Outside: Emergency release

• Inside: Push/turn button lock

• Indicator option available

• Bedroom/bathroom use

• Child-safe design

Passage Function

• Both levers always free

• No locking mechanism

• High-traffic suitable

• Smooth operation

• Minimal maintenance

Storeroom Function

• Outside: Always locked

• Inside: Always free

• Key entry only

• Storage security

• Commercial grade

Classroom Function

• Outside: Key locks/unlocks

• Inside: Always free

• Emergency egress

• Teacher control

• Safety compliant

Installation Guidelines

Door Preparation

• Cross Bore: 2-1/8" (54mm)

• Edge Bore: 1" (25mm)

• Backset: 2-3/8" or 2-3/4"

• Door Thickness: 1-3/8" to 1-3/4"

• Strike Plate: 2-3/4" x 1-1/8"

Installation Steps

1. Install latch in edge bore

2. Insert exterior lever assembly

3. Align with latch tail piece

4. Attach interior lever

5. Test operation

6. Install strike plate

Adjustment Features

• Adjustable latch for fit

• Reversible handing

• Variable rose positioning

• Fine-tune alignment

• Spring tension adjustment

Finish Options

Applications by Market

Residential

• Entry doors - 809 series

• Bedrooms - Privacy function

• Bathrooms - LH853 privacy

• Passages - 803 passage

• Closets - Passage function

Commercial

• Offices - 6491 SSET

• Conference - LH852 series

• Reception - Premium finishes

• Restrooms - Stainless steel

• Corridors - Heavy-duty

Healthcare

• Patient rooms - Anti-bacterial

• Operating - Stainless steel

• Public areas - ADA compliant

• Staff areas - Master keyed

• Emergency - Fail-safe options

Education

• Classrooms - Classroom function

• Offices - Entry function

• Dormitories - Privacy locks

• Libraries - Passage sets

• Laboratories - Storeroom

Hospitality

• Guest rooms - Hotel function

• Suites - Premium levers

• Public areas - Commercial grade

• Conference - Executive finish

• Restaurants - Stainless steel

Quality Assurance

Testing Standards

• Cycles: 200,000 to 1,000,000

• Force: ANSI/BHMA compliant

• Torque: 450 inch-pounds

• Finish: Salt spray tested

• Security: Pick resistant

Certifications

• ANSI/BHMA Grade 2 & 3

• ADA compliant designs

• UL listed (fire doors)

• CE marked (European)

• RoHS compliant

Warranty

• Mechanical: 5-10 years

• Finish: 1-5 years

• Lifetime options available

• Commercial coverage

• Residential programs

Why Choose Stahlock Lever Sets?

Superior Value

Commercial-grade quality at competitive prices with excellent ROI through durability.

Installation Efficiency

Quick installation with standard preparations reduces labor costs and time.

Aesthetic Versatility

Wide range of styles and finishes ensures perfect match for any design.

Reliable Performance

Tested beyond industry standards for consistent, trouble-free operation.

Ordering Information

How to Specify

1. Select Model: Choose series and style

2. Determine Function: Entry, privacy, passage

3. Choose Finish: Match existing hardware

4. Specify Backset: 60mm or 70mm

5. Door Thickness: Standard or extended

6. Keying: Individual or keyed alike

Complete Package Includes

• Interior and exterior levers

• Latch mechanism

• Strike plate and screws

• Installation instructions

• Keys (keyed functions)

• Warranty card

Contact Stahlock today for lever sets that combine style, security, and lasting performance for your projects.
